Bryant
One 2-Pole, 20 Amp and Two 1-Pole, 50 Amp,
120/240V,
Plug-In,
Includes Rejection Tab.
UL Listed.
All Type BD Duplex and BQ Quadplex circuit breakers carry listing for HACR applications. All 15 and 20 ampere single poles are switch duty rated.
1-30 Amp, 2 Pole and 1-20 Amp, 2 Pole,
120/240VAC, 10kAIC,
Common Trip, Quadplex Circuit Breaker with No Rejection Clip.
UL Listed.
CT2 suffix indicates 2 double poles
NC suffix stands for Non-CTL. CTL breakers have a rejection feature that prevents them from being used in certain areas of the load center. Non-CTL (NC) breakers do not have this feature, so they can fit into any available space in a load center.
1-40 Amp, 2 Pole and 1-20 Amp, 2 Pole,
120/240VAC, 10kAIC,
Common Trip, Quadplex Circuit Breaker with No Rejection Clip.
UL Listed.
CT2 suffix indicates 2 double poles
NC suffix stands for Non-CTL. CTL breakers have a rejection feature that prevents them from being used in certain areas of the load center. Non-CTL (NC) breakers do not have this feature, so they can fit into any available space in a load center.
2-40 Amp, 2 Pole,
120/240VAC,
Common Trip, Quadplex Circuit Breaker with No Rejection Clip.
UL Listed.
CT2 suffix indicates 2 double poles
NC suffix stands for Non-CTL. CTL breakers have a rejection feature that prevents them from being used in certain areas of the load center. Non-CTL (NC) breakers do not have this feature, so they can fit into any available space in a load center.
20 Amp and 30 Amp, 120/240 Volt, 4 Pole Quad Circuit Breaker, AIC Rating 10.
Equal to one 2 Pole, 20 Amp Breaker and one 2 Pole, 30 Amp Breaker. Takes 2 Plug-In 1-Pole Spaces.
30 Amp and 40 Amp, 120/240 Volt, 2 Pole Quad Circuit Breaker, AIC Rating 10.
Equal to one 2 Pole, 30 Amp Breaker and one 2 Pole, 40 Amp Breaker. Takes 2 Plug-In 1-Pole Spaces.
